Tool holders for Hanwha Swiss-type lathes — by machine model

Mongtec makes 34 tool holders for Hanwha sliding-headstock (Swiss-type) lathes: XD12, XD16, XD20, XD26, XD32, XD35, XD38, XE20, XE26, XDI20. Each one is listed with the Hanwha machine models it fits. Mongtec Precision is a Taiwanese brand headquartered in Taichung, Taiwan, and is not affiliated with Hanwha.

Request a quotation →

At a glance

Machine seriesXD12, XD16, XD20, XD26, XD32, XD35, XD38, XE20, XE26, XDI20
Holder typesAxial Live Tool Holder, Backworking Radial Milling Holder, 180-Degree Axial Live Tool Holder, Backworking Slitting Saw Holder, Adjustable-Angle Axial Live Tool Holder, Radial Milling Live Tool Holder, Radial Milling Holder, Dual-Spindle Axial Live Tool Holder, Polygon Milling Tool Holder, Slitting Saw Holder, Drilling Holder, Turning Tool Holder, Backworking Live Tool Holder
Gear ratios1:0.55, 1:0.6, 1:0.77, 1:1
Maximum speed4,000–8,000 rpm
ColletsER11, ER16, ER20
CatalogueHanwha Swiss Type Toolholders — Ver.2026.09, 21 pages, PDF

Find a holder by machine series

Each row lists every Mongtec holder the catalogue gives for that machine series. The full table below shows the exact machine versions.

Machine seriesMongtec holders
XD12XD20H-16230, XD20H-16330, XD20H-10130, XD20H-11130, XD20H-10810, XD20H-10310, XD12H-30210, XD12HIII-30210, XD12H-30410, XD12HIII-30410
XD16XD20H-16230, XD20H-16330, XD20H-10130, XD20H-11130, XD20H-10810, XD20H-10310, XD12HIII-30210, XD12HIII-30410
XD20XD20H-16230, XD20HII-16230, XD20H-16330, XD20HII-16330, XD20H-10130, XD20H-11130, XD20HII-10130, XD20HII-11130, XD20H-10810, XD20H-10310, XD20HII-10310, XD26HII-12110, XD20H-30310, XD20V-50210, XD20H-30210, XD20H-30410
XD26XD20H-16230, XD20HII-16230, XD20H-16330, XD20HII-16330, XD20H-10130, XD20H-11130, XD20HII-10130, XD20HII-11130, XD20H-10810, XD20H-10310, XD20HII-10310, XD26HII-12110, XD20H-30310, XD20H-30210, XD20H-30410
XD32XD32H-10130, XD32H-11110A, XD32H-11130, XD38HII-10120, XD32H-15030, XD32H-15130, XD38HII-15020, XD38HII-12110, XD38II-10410, XD38IIH-11030, XD38II-11510, XD32H-30210, XD32H-30410
XD35XD32H-10130, XD32H-11110A, XD32H-11130, XD38HII-10120, XD32H-15030, XD32H-15130, XD38HII-15020, XD38HII-12110, XD38II-10410, XD38IIH-11030, XD38II-11510, XD32H-30210, XD32H-30410
XD38XD32H-10130, XD32H-11110A, XD32H-11130, XD38HII-10120, XD32H-15030, XD32H-15130, XD38HII-15020, XD38HII-12110, XD38II-10410, XD38IIH-11030, XD38II-11510, XD32H-30210, XD32H-30410
XE20XD20HII-16230, XD20HII-16330, XD20HII-10130, XD20HII-11130, XD20HII-10310, XD26HII-12110, XD20H-30310, XD20H-30210, XD20H-30410
XE26XD20HII-16230, XD20HII-16330, XD20HII-10130, XD20HII-11130, XD20HII-10310, XD26HII-12110, XD20H-30310, XD20H-30210, XD20H-30410
XDI20XDI20-10120

All 34 models in the catalogue

Mongtec modelHolder typeGear ratioMax. speedColletCompatible machines
XD20H-16230180-Degree Axial Live Tool Holder1:16,000 rpmER11/ER16XD12II/XD16II/XD12III/XD16III/XD20/XD26/XD20V/XD20M
XD20HII-16230180-Degree Axial Live Tool Holder1:16,000 rpmER11/ER16XD20II/XD26II/XE20/XE26
XD20H-16330180-Degree Axial Live Tool Holder1:16,000 rpmER16XD12II/XD16II/XD12III/XD16III/XD20H/XD26H/XD20V/XD20M
XD20HII-16330180-Degree Axial Live Tool Holder1:16,000 rpmER16XD20II/XD26II/XE20/XE26
XDI20-10120Dual-Spindle Axial Live Tool Holder1:16,000 rpmER16XDI20
XD20H-10130Axial Live Tool Holder1:16,000 rpmER16XD12II/XD16II/XD12III/XD16III/XD20H/XD26H/XD20V/XD20M
XD20H-11130Axial Live Tool Holder1:16,000 rpmER11/ER16XD12II/XD16II/XD12III/XD16III/XD20H/XD26H/XD20V/XD20M
XD20HII-10130Axial Live Tool Holder1:16,000 rpmER16XD20II/XD26II/XE20/XE26
XD20HII-11130Axial Live Tool Holder1:16,000 rpmER11/ER16XD20II/XD26II/XE20/XE26
XD32H-10130Axial Live Tool Holder1:16,000 rpmER16XD32H, XD35H, XD38H
XD32H-11110AAxial Live Tool Holder1:16,000 rpmER11/ER16XD32H/XD35H/XD38H
XD32H-11130Axial Live Tool Holder1:16,000 rpmER11/ER16XD32/XD35/XD38/XD32II/XD38II
XD38HII-10120Axial Live Tool Holder1:16,000 rpmER20XD32/XD35/XD38/XD32II/XD38II
XD20H-10810Polygon Milling Tool Holder1:0.66,000 rpm—XD12II/XD16II/XD12III/XD16III/XD20/XD26/XD20V/XD20M
XD32H-15030Adjustable-Angle Axial Live Tool Holder1:16,000 rpmER16XD32/XD35/XD38/XD32II/XD38II
XD32H-15130Adjustable-Angle Axial Live Tool Holder1:16,000 rpmER11/ER16XD32/XD35/XD38/XD32II/XD38II
XD38HII-15020Adjustable-Angle Axial Live Tool Holder1:16,000 rpmER20XD32/XD35/XD38/XD32II/XD38II
XD20H-10310Radial Milling Live Tool Holder1:18,000 rpmER16XD12/XD16/XD12II/XD16II/XD12III/XD16III/XD20/XD26/XD20V/XD20M
XD20HII-10310Radial Milling Live Tool Holder—6,000 rpmER16XD20II/XD26II/XE20/XE26
XD26HII-12110Radial Milling Holder1:16,000 rpmER16XD20II/XD26II/XE20/XE26
XD38HII-12110Radial Milling Holder1:16,000 rpmER16XD32/XD35/XD38/XD32II/XD38II
XD38II-10410Slitting Saw Holder1:14,000 rpm—XD32/XD35/XD38/XD32II/XD38II
XD38IIH-11030Drilling Holder———XD32/XD35/XD38/XD32II/XD38II
XD38II-11510Turning Tool Holder———XD32/XD35/XD38/XD32II/XD38II
XD20H-30310Backworking Live Tool Holder1:18,000 rpmER16XD20/XD26/XD20M/XE20/XE26
XD20V-50210Backworking Radial Milling Holder1:16,000 rpmER16XD20V
XD12H-30210Backworking Radial Milling Holder1:0.55—ER11XD12H
XD12HIII-30210Backworking Radial Milling Holder1:0.55—ER11XD12III/XD16III
XD20H-30210Backworking Radial Milling Holder1:0.554,000 rpmER11XD20/XD26/XD20M/XE20/XE26
XD32H-30210Backworking Radial Milling Holder1:0.774,000 rpmER16XD32/XD35/XD38/XD32II/XD38II
XD12H-30410Backworking Slitting Saw Holder1:0.554,000 rpm—XD12H
XD12HIII-30410Backworking Slitting Saw Holder1:0.554,000 rpm—XD12III/XD16III
XD20H-30410Backworking Slitting Saw Holder1:0.554,000 rpm—XD20/XD26/XD20M/XE20/XE26
XD32H-30410Backworking Slitting Saw Holder1:0.774,000 rpm—XD32H/XD35H/XD38H

Source: Hanwha Swiss Type Toolholders, Ver.2026.09. A dash means the catalogue does not state the value; it is confirmed at RFQ. Main dimensions are in the PDF; dimensioned drawings are supplied by email once the enquiry is open.

How to use this cross-reference

  1. Find your Hanwha machine model, for example XD20H, XD26H, XD32H.
  2. Pick the holder type you need and check that your machine model is listed.
  3. Send us the machine model, the station and the part number. Mongtec engineering confirms the fit before quoting.

Frequently asked

Which Mongtec holders fit the Hanwha XD20?

The catalogue lists 16 holders for the XD20: XD20H-16230, XD20HII-16230, XD20H-16330, XD20HII-16330, XD20H-10130, XD20H-11130, XD20HII-10130, XD20HII-11130, XD20H-10810, XD20H-10310, XD20HII-10310, XD26HII-12110, XD20H-30310, XD20V-50210, XD20H-30210, XD20H-30410.

My part number is not in the table. Can Mongtec still supply it?

A part number missing from the catalogue does not mean Mongtec cannot make it. Send the part number of the holder you use now, or a competitor's part number, and engineering will work out the matching holder and quote it.

Where do I get dimensions and drawings?

Main dimensions are in the free PDF catalogue on this page. Dimensioned drawings for a specific holder are supplied by email once the enquiry is open.

Download the Hanwha catalogue (PDF)

Hanwha Swiss Type Toolholders

Hanwha Swiss Type Toolholders (PDF)

Hanwha Swiss Type Toolholders — Ver.2026.09, 21 pages, PDF · Free download, no registration.

Get a quote

Send the machine model, the station you want to use and the part number you are replacing. An incomplete enquiry is still worth sending: Mongtec works out the rest from the machine model.

Request a quotation →
