What is in the catalogues, and what is not. The catalogues give you the selection data — sizes, tapers, clamping ranges, balance grades, standards, article numbers and the dimensioned drawings. What they cannot tell you is whether a given holder fits your machine: the spindle taper, the pull stud and the stop arrangement decide that, and they differ between machine builders. Mongtec engineering confirms the fit against your actual machine before quoting, and that check is free. Send us the machine and the operation →
One document introducing everything Mongtec makes: product families, what each one is for, and which machines they suit. Start here if you want an overview rather than a dimension.
The detailed documents: dimensions, interface sizes, clamping ranges, speeds, torque and article numbers. These are what you select and order from.
Catalogues are updated continuously — always download the current file.
| Shrink Fit Toolholder (PDF) | BT, BBT, SK, CAT and HSK shrink fit chucks. 4.5° standard, 4.5° through-coolant and 3° slim, bores 3–32 mm and 1/8″–1-1/4″, balanced G2.5/25,000 rpm. Includes extensions, modular heads, shrink ER collets and the induction machine. |
|---|---|
| Hydraulic Toolholder (PDF) | Hydraulic chucks in BT, BBT, SK, CAT, HSK and MTB. Standard, power, 3° slim, mould, grinding, short and Swiss-type forms, plus reducing sleeves from 3 to 25 mm. Actuates with a hex key. |
| BT / BBT Tooling System (PDF) | Twenty-five holder types on BT and BBT tapers to JIS B 6339: ER, power milling, OZ, TG, SKS, face mill (metric and inch), Weldon, whistle notch, adapters, drill and tapping chucks, test arbors. Taper tolerance tighter than AT3, HRC 56–60, Ra below 0.2 µm. |
| HSK-A Tooling System (PDF) | The HSK-A range from HSK32A to HSK100A, balanced G2.5 at 25,000 rpm throughout. ER, power milling, face mill, Weldon, whistle notch at 2°, Morse adapters, HSK-A to HSK-C sleeves. |
| HSK-T Tooling System (PDF) | HSK-T turning tools for mill-turn centres and multi-axis lathes: boring bar holders, square-shank blocks and 38 integral ISO 5608 turning tool designations in HSK40T to HSK100T. |
| Coolant Powered Gripper (PDF) | Bar gripper driven by the machine coolant line or compressed air. Clamps 0 to 80 mm at 0.5 bar, withstands 280 psi, carbide-tipped jaws, holds hexagonal stock. |
| Zero Nut (PDF) | ER16 to ER40 collet nut with six precision adjusting screws. Corrects spindle or holder misalignment to a target runout of 0.002 mm, made to work with AA grade collets. |
| Centers, Face Drivers and Pipe Centers | Rotary and fixed centers, MFC face drivers and pipe centers on Morse tapers MT2 to MT6. Runout 0.003 mm live and 0.002 mm dead, triplex bearings, carbide points at HRA 90–91. |
|---|
The catalogues are organised by interface, not by machine. If you are not sure which interface your turret or spindle uses, start from the machine builder index — over 80 builders with the turret interface published where it is known. Or read BMT or VDI? How to tell which turret you actually have.
