| Mongtec model | 66151 |
|---|---|
| Machine brand | Star |
| Star reference code | 66151 |
| Holder type | Radial 3 spindles toolholders |
| Max tool shank | 10.0 mm |
| Holder shank diameter | 34 mm |
| Collet | ER16 |
| Drive | Driven (live) — ratio 1:1 |
| Max speed | 6,000 rpm |
| Brand | Mongtec Precision Inc. |
Source: Mongtec Swiss Type Toolholders catalogue, Ver 2026.07.
Swiss-type (sliding headstock) lathes hold their tooling in fixed positions on a gang or comb layout rather than in a rotating turret. Each position is machine-specific: the holder body, the mounting face and the drive coupling are defined by the machine builder, which is why a Swiss-type holder is identified by the builder's own reference code rather than by a BMT or VDI size.
66151 is a driven position — the tool spindle turns at 1:1 to the machine's live-tool drive, up to 6,000 rpm. Usable speed is whichever is lower: this rating or your machine's drive rating.
Mongtec supplies 66151 to the Star reference 66151, so it occupies the same holder position on the machine. That reference is the fastest way to specify what you need: quote the code from your machine's tooling list and Mongtec engineering matches it, then confirms the fit against your actual machine and station before quoting.
Star is a registered trademark of its respective owner. Mongtec Precision is an independent tooling brand with no affiliation to, endorsement by or licence from Star. The Star reference code is quoted only to identify which holder position and machine the Mongtec part is built for; fit is confirmed by Mongtec engineering at RFQ.
| Model | Type | Max tool shank | Collet | Drive |
|---|---|---|---|---|
| 33150 | Axial toolholders | 10.0 mm | ER16 | 1:1 · 8,000 rpm |
| 57161 | Axial toolholders | 10.0 mm | ER16 | 1:1 · 6,000 rpm |
| 67161 | Radial 6 spindles toolholders | 10.0/7.0 mm | ER16/ER11 | 1:1 · 6,000 rpm |
| 54121-01 | Static drilling toolholders | 10.0 mm | ER16 | Static |
| 0R122 | Static drilling toolholders | 10.0 mm | ER16 | Static |
| 0R123 | Static drilling toolholders (internal coolant) | 10.0 mm | ER16 | Static |
| 67127 | Static drilling toolholders (internal coolant) | 10.0 mm | ER16 | Static |
| B2E22 | Static drilling toolholders (internal coolant) | 6/8/10/12/16 mm | — | Static |
| STAR34322 | Static 3 toolholders | 22 mm | — | Static |
The drawing above is the published catalogue drawing, and the dimension letters are the columns of the table below. What Mongtec confirms for you is the interface on your machine, the reach for the operation, and the final article number. Send the machine and the operation; the check is free.
Send my machine and get the article number →66151 is built to the Star reference 66151 for Star Swiss-type (sliding headstock) lathes. Holder positions differ between machine generations, so send Mongtec your machine model and the station you want to use and engineering confirms the fit before quoting.
Mongtec supplies 66151 to the Star reference so that it occupies the same holder position. Mongtec is an independent tooling brand and is not affiliated with Star; interchange in your specific machine and setup is confirmed by Mongtec engineering at RFQ.
66151 takes tools up to 10.0 mm using ER16 collets, on a 34 mm holder shank. Collets are supplied separately — tell Mongtec the shank diameters you intend to run and they are quoted with the holder.
Send the machine model, the station you want to use and the tools you intend to run. Anything you do not know, Mongtec works out from the machine model — an incomplete enquiry is still worth sending. Dimensioned drawings are supplied by email once the enquiry is open.
